FJ.HOOK: ALN Optional Vena Cava Filter w/Hook & Introducer System, 32mm x 59mm, 7F x 60cm, Jugular (No Box)

In-Date » ALN » Vena Cava

ALN FJ.HOOK Optional Vena Cava Filter, Jugular

The device is an Optional Vena Cava Filter - Jugular Kit with Hook. It consists of a nine legs 316L stainless steel filter with a hook at the apex supplied with a delivery kit including a puncture needle, a J guidewire, a 7F introduction sheath, a dilatator and a pusher catheter. The filter is pre-packaged in a filter holder designed to facilitate the insertion of the filter in the introducer sheath.

Product Code: FJ.HOOK

• Maximum Diameter of the Vena Cava: 32mm
• Filter Length: 59mm
• Introducer Sheath: 7F x 600mm
• Includes
  • ALN Filter in Holder
  • Dilator
  • Introducer Sheath
  • Pushing Catheter
  • Puncture Needle
  • J-Tip Guidewire

ALN Vena Cava Filter Product Options

• FJ.120096: Jugular Kit 32mm x 55mm, 7F x 600mm
• FB.010500: Brachial Kit 32mm x 55mm, 7F x 1200mm
• FF.010995: Femoral Kit 32mm x 55mm, 7F x 600mm
• FJ.HOOK: Jugular Kit w/Hook 32mm x 59mm, 7F x 600mm
• FB.HOOK: Brachial Kit w/Hook 32mm x 59mm, 7F x 1200mm
• FF.HOOK: Femoral Kit w/Hook 32mm x 59mm, 7F x 600mm

Sterilization

• Device Packaged as Sterile: Yes
• Requires Sterilization Prior to Use: No
• Single-Use
• Disposable

Additional Details

• Company Name: A.L.N.
• FDA Product Code: DTK
• FDA Product Code Name: Filter, Intravascular, Cardiovascular
• GMDN Term Code: 44864
• GMDN Term Name: Vena cava filter, temporary/permanent
• GMDN Term Definition: A vascular device intended to be percutaneously implanted in the inferior vena cava (IVC) to prevent pulmonary embolism (PE); it can be retrieved before a threshold period or remain as a permanent implant after the period. It achieves its unconstrained diameter upon deployment in the IVC and imparts an outward radial force on the luminal surface of the vena cava to ensure proper positioning and stability. It is designed for blood clot capture while maintaining caval patency. It is made of metal alloys [e.g., stainless steel, titanium (Ti), nickel-titanium alloy (Nitinol)] and is available in various self-expanding designs (e.g., conical, basket). This is a single-use device.

ALN Implants Chirurgicaux is a French medical device company specializing in the design and manufacture of vena cava filters for the prevention of pulmonary embolism. The company is best known for the ALN Optional Vena Cava Filter, an optionally retrievable stainless steel IVC filter engineered for both temporary and permanent placement. ALN products are recognized worldwide for their precision engineering, biocompatibility, and advanced anti-tilt design that ensures reliable positioning within the inferior vena cava. With a global distribution network and decades of clinical use, ALN continues to innovate in the vascular intervention space, providing interventional radiologists, vascular surgeons, and cardiologists with safe and effective solutions for thromboembolic disease management.
